Valve Size: 1/2” - 20”.
Valve Pressure Rating: Class 150 – 600.
Standards:
|
Design & Manufacture |
ASME B 16.34 |
|
Face to Face |
ANSI B16.10 |
|
Flange Ends Dimension |
ASME B16.5 |
|
BW End Dimension |
ASME B16.25 |
|
Pressure-temperature Ratings |
ASME B16.34 |
|
Inspection & Test |
API 598 |
Standard Material Specifications
|
Part Name |
Material |
|||
|
1 |
Body |
ASTM A216 WCB |
ASTM A351 CF8 |
ASTM A351 CF8M |
|
2 |
Screen |
ASTM 182 F304 |
ASTM A 182 F304 |
ASTM A182 F316 |
|
3 |
Bonnet Bolt |
ASTM 193 B7 |
ASTM 193 B8 |
ASTM 193 B8 |
|
4 |
Bonnet Nut |
ASTM 194 2H |
ASTM 194 8 |
ASTM 194 8 |
|
5 |
Gasket |
Graphite+SS304 |
Graphite+SS304 |
Graphite+SS316 |
|
6 |
Bonnet |
ASTM A216 WCB |
ASTM A351 CF8 |
ASTM A351 CF8M |
Manufacturer: China Xinhai Valve Manufacturer Company
